Industry Washable Cleaning PCB Remove Dust Silicone Sticky Roller For Cleaning Machine

Industry Washable Cleaning PCB Remove Dust Silicone Sticky Roller For Cleaning Machine

  • Industry Washable Cleaning PCB Remove Dust Silicone Sticky Roller For Cleaning Machine
  • Industry Washable Cleaning PCB Remove Dust Silicone Sticky Roller For Cleaning Machine
  • Industry Washable Cleaning PCB Remove Dust Silicone Sticky Roller For Cleaning Machine
  • Industry Washable Cleaning PCB Remove Dust Silicone Sticky Roller For Cleaning Machine
  • Industry Washable Cleaning PCB Remove Dust Silicone Sticky Roller For Cleaning Machine
Industry Washable Cleaning PCB Remove Dust Silicone Sticky Roller For Cleaning Machine
Product Details:
Place of Origin: China
Brand Name: allesd
Certification: ISO/SGS/CTI
Model Number: SR0220
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 4", 200rolls/carton; 6"/8", 100rolls/carton; 10"/12", 50rolls/carton
Delivery Time: 10-15days
Payment Terms: T/T
Supply Ability: ~200,000 rolls per month
Contact Now
Detailed Product Description
Name: Washable Cleaning PCB Remove Dust Silicone Sticky Roller Material: Silicon+Stainless Steel Central Shaft
Size: Customized Sizes Tackiness: High, Medium, Low, No Tackiness
Certificate: RoHS MSDS Color: Blue ( Support Custom Other Colors)
Feature: Tiny Dust Particles Removal Application: For Cleaning Machine
High Light:

PCB Silicone Sticky Roller

,

Remove Dust Cleanroom Sticky Roller

,

Industry Cleaning Silicone Sticky Roller

Replaceable Reusable Industry Washable Cleaning PCB Remove Dust Silicone Sticky Roller for Cleaning Machine


Washable Cleaning PCB Remove Dust Silicone Sticky Roller
Constructions:PDMS(Polydimethylsiloxane)
Roller:Silicon
Pipe:Aluminium and Bearings
Standard Width:All sizes are customized on drawings
Roller Color:blue
Handle:Aluminum alloy
Frame:Aluminum alloy
Tackiness:None/Low/Middle/High
Protective film:PET
Applications:Applicable to breadboard, PCB, LCD, SMT, clean room, stainless steel sheet, film for dusting and etc.


General Physical Properties:

Roller Diameter/mm: 112.4
Hardness(shore A): 25-30degree
Tear Strength(KM/M): 19.08
Tensile Strength (MPa): 5.3
Elongation at Break(%): 611
Impact elasticity(%): 43
Thickness of Protective film/µm: 40±5



Performance Testing:

Rotation: Flexible, no abnormal sound
Crumbs Test: No drop litter when roll over 60,000 times
Hardness Testing: 25-30
Packing: 1pcs/opp shielding bag



Features:


1.Its surface is smooth like mirror, can pick up particulates’ size below 2um.
2.It is effectual in adhering to hair, scurf, dust or other impurities.
3.It is easy to transfer impurities to sticky paper, so that prolong the self-adhesiveness of silicon.
4.Reusable and washable



Instructions for using silicone roller:


1. Correct usage: when using silicone roller, please roll backward. (especially clean uneven products, such as PCB board) In this way, the service life of silicone adhesive can be prolonged, and the support can not be easily deformed and the screws can be prevented from loosening.
2. Cleaning silicone sticky roller: please clean the silicone sticky roller with clean water or soapy water, wipe it dry or air
dry it naturally.
3. Do not contact benzene and ester solvents (such as Tianna water, net washing water, phenanthrene water, ethyl acetate, etc.) during use. Once in contact, wipe it quickly with anhydrous alcohol and dry it with an air gun.
4. After every 5000 times of use, if the viscosity drops significantly, clean it with clean water, wrap it with clean packaging film, and place it for 48 hours, the viscosity also rises.
5. The service life of our silicone sticky roller is more than 10000 times



Precautions for silicone roller:


1. It is strictly prohibited to use benzene and ester solvents (such as Tianna water, net washing water, phenanthrene water, ethyl acetate, etc.) to clean the silicone adhesive. Such solvents will cause the silicone adhesive to expand, age, deform, and reduce the viscosity quickly.
2. Please do not use silicone rubber wheels to clean the ground, wall and rough board surface: it is easy
to scratch the silicone sticky roller.
3. Please do not scratch the silicone with a sharp blade.



Maintenance and storage of silicone sticky roller:



After use:
please use the silicone sticky roller to roll back and forth on the sticky paper book several times to keep the
silicone sticky roller clean.
Storage:
please keep away from benzene solvents, inks and curing agents and put them in clean packaging.
When not in use:
please avoid high temperature environment and direct sunlight.



Industry Washable Cleaning PCB Remove Dust Silicone Sticky Roller For Cleaning Machine 0



About Us:



Established in 2011, Suzhou Quanjuda Purification Technology Co., LTD is a leading manufacturer and exporter of various ESD & Cleanroom products, offers a full line of ESD & Cleanroom equipment and supplies, providing comprehensive services by manufacturing, sourcing and exporting products from China.



Other Products we Supply:

  • Cleanroom Apparels(Disposable, Launderable)
  • Cleanroom Cleaning Supplies(Wipes, Tacky Rollers, Mops, Brushes, Swabs),
  • Cleanroom &ESD Chairs/Stools,
  • Cleanroom Documentation(Paper, Pen, Notebook),
  • Cleanroom Gloves(Finger Cots, PU Coated Glove, PVC Dotted Glove)
  • Cleanroom Mats(Sticky Mat, Table/Floor Mat, Anti-fatigue Mat),
  • ESD Package Materials(Bags, Tapes etc),
  • ESD Storage Materials (Bins, Trays, Circulation Box, Solvent Dispensers),
  • ESD Wrist/Heel Straps/Grounding Cords.
  • Static Control Ionizing Blower/Gun/Nozzle,
  • Illuminated Magnifier,
  • Cleanroom Curtain and etc

FAQ:



● Q1: Are you a manufacturer?
①.Ans:Yes, we have been in manufacturing and providing excellent Cleanroom and ESD solutions for customers more than 10years.
②.Our own production plants and a wide network of suppliers who are strictly selected, are totally qualified for ISO Quality Management System.
● Q2: How long could you prepare samples?
Ans:Normally 1days if we have the sample onhand. If customized one, about a week around.
● Q3: How about batch order production?
Ans: Normally 3-7days or so
● Q4: Do you inspect the finished products?
Ans:Yes, we will do inspection according to ISO standard and ruled by our QC staff.
● Q5: How do you ship the goods?
Ans: By sea, by air, by truck or by courier (UPS, DHL, Fedex, TNT etc.)
● Q6: What advantage do you have?
Ans:
①.We have professional engineers, customers can expect the best possible advice and support.
②.Related responsible team to answer all your questions and follow-up process for you and do update in time
③.Strict and standard process control according to Quality Management System.
④.Documents support on products, we have strong technical data sheet to support our products, which could make you easier to know our products.
