Lint Free Static Elimination Antistatic Air Gun High Efficiency

Lint Free Static Elimination Antistatic Air Gun High Efficiency

  • Lint Free Static Elimination Antistatic Air Gun High Efficiency
  • Lint Free Static Elimination Antistatic Air Gun High Efficiency
  • Lint Free Static Elimination Antistatic Air Gun High Efficiency
  • Lint Free Static Elimination Antistatic Air Gun High Efficiency
Lint Free Static Elimination Antistatic Air Gun High Efficiency
Product Details:
Place of Origin: china
Brand Name: allesd
Model Number: SL-005B
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 1pc/bag
Delivery Time: 7-10 working days
Payment Terms: T/T
Supply Ability: 100,000pcs per month
Contact Now
Detailed Product Description
Product Name: SL-005B Static Elimination Antistatic Air Gun Operating Voltage: 5.6kv
Current Consumption: 4.5MA Ozone Generation: 0.03 PPM
Max Air Pressure: 70PSI Min Air Pressure: 40 PSI
Air Velocity: 10 M / Sec Operating Temperature: 32 º F (º C) - 122 º F (50 º C)
Application: Industry
High Light:

Static Elimination Antistatic Air Gun

,

Lint Free Antistatic Air Gun

,

ESD Safe Materials Air Gun

High Efficiency Lint Free Static Elimination Antistatic Air Gun



Safety ESD Antistatic Ionizing Air Gun/static Ionizing Air Nozzle



Humidity ≤ 60%
Ambient temperature 220C
Working voltage 5.6KV
Current consumption ≤ 350uA
Operating temperature 32 º F (º C) - 122 º F (50 º C)
Compressed air pressure 40-100psi Ozone amount:0.03PPM (measured 6 inches in front of the air nozzle)
Test voltage 5KV~500V
Current Consumption 4.5MA
Ozone Generation 0.03 PPM
Max Air Pressure 70PSI
Min Air Pressure 40 PSI
Air velocity 0.03ppm
Operating Air Velocity 10 m / sec



Product features:


1. Neutralize static electricity quickly
2. Strong ionic air flow
3. The air nozzle has good grounding protection



IONIZING AIR NOZZLE


Antistatic Ionizing nozzle is the ideal technique of removing static, contaminants and dust from three-dimensional parts before assembling, packaging, painting or finishing. The ion air nozzle neutralizes the static electricity and cleans at distances up to 2 feet. When ordinary compressed air is used to remove dust and air nozzle for cleaning purpose, its efficiency gets reduced. In case the static charge, which holds the dust to the product is not neutralized, both the product and the dust will remain statically charged and capable of re-contamination.

The ion air nozzle is rugged in design and an industrialized ionizing air nozzle. We are manufacturers of air nozzle and we are providing ionizing nozzle with or without stand. Air gun nozzle is mainly used to eliminate static charges and blow off contaminants from the surface of laminated woods, plastics, rubbers and glass. At the same time the neutral surface doesn't re-attract airborne contaminants from the manufacturing process. If the compressed air is ionized, the static charge will be eliminated, which allows superior quality cleaning without re - attraction.



How Ionizing Air Nozzle Works :


The air nozzle and an ionization head engineered into the finger guard.When the trigger is pulled air travels at high speed from the nozzle, picking up the ionized air produced by the ionization head. The ionized air is blown at high speed towards the object. The ionization kills the static electricity, allowing the dust to be blown off. The object will be static-free and unable to re-attract dust.


Note: Air filter can be installed if necessary.
