10e6ohm Antiestatica Cleanroom Conductive Lint Free Polyester ESD Safe Anti-static Fabric for Lab Coat

10e6ohm Antiestatica Cleanroom Conductive Lint Free Polyester ESD Safe Anti-static Fabric for Lab Coat
10e6ohm Antiestatica Cleanroom Conductive Lint Free Polyester ESD Safe Anti-static Fabric for Lab Coat

Large Image :  10e6ohm Antiestatica Cleanroom Conductive Lint Free Polyester ESD Safe Anti-static Fabric for Lab Coat

Product Details:
Place of Origin: China
Brand Name: allesd
Certification: ISO/SGS
Model Number: AF0080
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 1roll/knitting bags
Delivery Time: 15-25 working days
Payment Terms: T/T
Supply Ability: 1,500,000 meters per month
Detailed Product Description
Material: 98% Polyester 2% Carbon Fiber Color: All
Width (cm): 150 Weight (gr/sqm): 115
Weave Style: Twill 1/2 Surface Resistivity: 106 ~ 108ohms
Package: 1roll/knitting Bags Functions: Anti-static, Lint Free
High Light:

Twill Woven Polyester ESD Fabric

,

5mm Grid ESD Fabric

,

108ohms ESD Fabric

All Colors Twill Woven Polyester Fabrics Dust Free Anti-static Fabric 5mm Grid for Functional Garments





ESD Fabric 5mm Grid(Checked): AF0080



Description: Anti-static ESD Woven Polyester Fabric, 5mm Grid

Applications: ESD protection in clean rooms, work wear



Features:

1) It is also called"conductive silk", and it adopts the special polyester filament and high quality conductive yarns

2) It is used for sewing ESD functional garments, which offers good resistance to static, chemicals and abrasion.

3) It is designed for Class 1000 cleanrooms and higher.

4) And it is applicable in electronics, medicals, biology, optics, spaceflight industries etc

5) Meets ESD standards EN 1149-1:2006, surface esistance below 107ohms



Specifications:

Spec Value Test Method
Material 98% Polyester 2% Carbon Fiber
Available Colors All
Carbon Configuration Grid 5mm
Width (cm) 150
Weight (gr/sqm) 115~120
Surface Resistivity (ohm/unit) 106 ~ 109
Friction charges (V) <150

Number of yarns (denier)

Warp

Weft



100

100


Weave style Twill 1/2
Air permeability (cc/cm²/sec) 30
Recommended Class Of Cleanroom Class 1000~10000

































10e6ohm Antiestatica Cleanroom Conductive Lint Free Polyester ESD Safe Anti-static Fabric for Lab Coat 0

10e6ohm Antiestatica Cleanroom Conductive Lint Free Polyester ESD Safe Anti-static Fabric for Lab Coat 1





10e6ohm Antiestatica Cleanroom Conductive Lint Free Polyester ESD Safe Anti-static Fabric for Lab Coat 210e6ohm Antiestatica Cleanroom Conductive Lint Free Polyester ESD Safe Anti-static Fabric for Lab Coat 310e6ohm Antiestatica Cleanroom Conductive Lint Free Polyester ESD Safe Anti-static Fabric for Lab Coat 4
